3 Components and power supply
USB
Wi-Fi
LAN Switch
Eth WAN
Cell
Coverage
(1, 2, 3, 4)

3.1.2 Rear panel

The following image shows the rear panel of the Teldat M1 router, which contains the majority of connectors.
6
Tricolor
Bicolor
Tricolor
Tricolor
Tricolor
Monochrome Blue
data is being transferred).
Off -> system stopped.
Red -> The interface is unavailable because it is being
installed, is disabled (shutdown), or has failed a self-test.
Amber -> idle.
• Rapid blinking. The device is not registered with the
network or there is insufficient quality.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Blinking (green/red) -> activity/maintenance.
Red -> interface down.
Green -> interface up.
Blinking (green/red) -> activity/maintenance.
Green -> connected. Blinking: data is being transferred.
Red -> disconnected.
Green -> connected. Blinking: data is being transferred.
Amber -> blinking: auto test.
Red -> disconnected.
Off -> system stopped.
Red -> The interface is unavailable because it is being
installed, is disabled (shutdown), or has failed a self-test.
Amber -> idle.
• Rapid blinking. The device is not registered with the
network or there is insufficient quality.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Green -> connected. Blinking: data is being transferred.
Shows the coverage level for the internal 3G module,
ranging from level 0 (all LEDs off) to level 4 (all lit up).
