Appendix B Radio information
In accordance with Article 10(8) of the Radio Equipment Directive 2014/53/EU, the following tables provide informa-
tion on frequency bands and RF transit power levels:
B.1 WWAN specifications
GSM / GPRS / EDGE (2G) capable models
Bands
EGSM (900)
DCS (1800)
WCDMA (3G, UMTS) capable models
Bands
Band 1 (2100)
Band 8 (900)
LTE (4G) capable models
Bands
Band 1 (2100)
Band 3 (1800)
Band 7 (2600)
Band 20 (800)
This product is supplied with YWX-6221SAX9-508 antennas. To comply with the regulations, do not choose other
antennas.
B.2 WIFI specifications
Wi-Fi Radio communications comply with the 802.11a/b/g/n standards.
WI-FI
2,4 GHz
5 GHz with TPC *
5 GHz with TPC *
5 GHz without TPC *
5 GHz without TPC *
Teldat Router M1/M1L
Frequency Range
Tx: 880–915 MHz
Tx: 1710–1785 MHz
Frequency Range
Tx: 1920-1980 MHz
Tx: 880–915 MHz
Frequency Range
Tx: 1920-1980 MHz
Tx: 1710–1785 MHz
Tx: 2500–2570 MHz
Tx: 832–862 MHz
Frequency Range
Tx: 2400-2483,5 MHz
Tx: 5150-5350 MHz
Tx: 5470-5725 MHz
Tx: 5150-5250 MHz
Tx: 5250-5350 MHz
Transmitted power
GMSK: Class 4, 33 dBm max.
8PSK: Class E2, 27 dBm max
GMSK: Class 4, 33 dBm max.
8PSK: Class E2, 27 dBm max
Transmitted power
Class3, 24 dBm max
Class3, 24 dBm max
Transmitted power
Class 3, 23 dBm max.
Class 3, 23 dBm max.
Class 3, 23 dBm max.
Class 3, 23 dBm max.
Transmitter power
20 dBm max
23 dBm max.
30 dBm max.
23 dBm max.
20 dBm max.
