3.8 SIM card installation

You may need to insert a SIM card in the Teldat M1 before you can use the WWAN interface. Some countries have
services (CDMA) that do not require SIM cards.
The Teldat M1 has two SIM trays.
One is located on the rear panel of the router, as shown in the following figure:
External module SIM tray
Fig. 23:
To insert the SIM card in the external SIM tray, first turn the device so that you can see the rear panel (see figure
23), and then carry out the following steps:
(1) Press the button until the SIM tray comes out.
(2) Place the SIM on the tray.
(3) Insert the tray in the slot and push it back in.
Inserting the SIM in the external module
Fig. 24:
The other SIM tray is internal. To access it, you need to open the flap on the underside of the router (as shown in the
following figure) and insert the SIM card.
