3 Components and Power Supply
LED
Left
Right
SFP/SFP+ interface LEDs
Fig. 5:
The table below provides information on the LEDs associated with the SFP/SFP+ interfaces:
SFP/SFP+ LED indicators
LED
Green

3.1.2 Rear panel

The following figures show the rear panel.
Rear panel
Fig. 6:
Rear panel
Fig. 7:
The following table provides information and a description of each component:
Rear panel components
Item
A
6
Description
Ethernet link connection and activity
Ethernet link speed
Description
Ethernet link connection
(Single PSU version)
(Dual PSU version)
Description
Bonding screw for protective earth.
State
Off -> Link has not been detected.
Yellow -> Link detected. Right LED indicates
speed status.
Blinking: connection data activity.
Off -> No link or 10M link.
Green -> 100M link.
Yellow -> 1000M link.
State
Off -> Link has not been detected.
On -> Link detected. Blinking: connection
data activity.
Teldat S.A.
Teldat Edge Router Atlas-840
