3 Components and Power Supply
L
100
LNK

3.1.2 Rear Panel

The following figure illustrates the rear panel:
Rear Panel
Fig. 4:
The rear panel elements are as follows:
Rear panel elements table
Item
A
8
Cellular interface corres-
ponding to the active SIM
Associated to each Ether-
net switch connector
(LAN1...LAN6)
Associated to each Ether-
net switch connector
(LAN1...LAN6)
Description
COM1, COM2. DCE RS-232 serial ports.
Note: These are only available in the following Regesta-PRO-ER models: 003,
013, 103 and 113.
Green
Yellow
Red
Off
Amber
Green
established.
The device is connected to
the ADSL network.
Coverage level above -
90dBm.
Coverage level between -90
dBm and -100 dBm.
Coverage level below -
100dBm.
Cellular interface is not act-
ive.
ON # Connection at 100
Mbps
OFF # Connection at 10
Mbps
ON # Ethernet connection
(link) established:
- Steady light: Data is not
being transferred.
- Flashing: Data is being
transferred.
Regesta-PRO-ER
