Technical information
A.6.6 USB interface
3G USB MODEMS
SPEED
CONNECTOR
A.6.7 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.6.8 Power supply
INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN
A.6.9 External power supply
INPUT VOLTAGE
INPUT FREQUENCY
A.6.10 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.6.11 Environmental specifications
TEMPERATURE
RELATIVE HUMIDITY
32
Please see the Teldat website http://www.teldat.com to get a list of the supported
3G USB modems.
The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de-
pends on the 3G USB modem used.
USB Type A.
V.24 9600-8-N-1 without flow control.
RJ45 female on the device's front panel.
+12V DC
1600 mA
5.5 mm
2.5 mm
100 - 240 V AC.
50-60 Hz.
Desktop / chassis for a 1 U high Rack mount enclosure.
245 x 210 x 45 mm.
1.4 kg.
OPERATING NORMALLY: 0 ºC to 45 ºC
STORED: -25 ºC to 70 ºC
On: 5 % to 90 %
