Technical information
A.5.4 WLAN connector (male)
A.5.5 USB connector
USB Type A
A.5.6 Configuration connector
RJ45 CONFIGURATION
A.5.7 Power supply connector
PIN
Internal
External
30
PIN
Internal
External
PIN
1
2
3
4
Shell
RJ45 PIN
1
2
3
4
5
6
7
8
ANT
POSITIVE
NEGATIVE
ANT
RF in/out
GND
USB
VCC
DATA-
DATA+
GND
Shield
CONF
--
RxD
GND
--
--
GND
TxD
--
