We recommend connecting all data devices to the same power source, regardless of whether the work-
place has an uninterrupted power supply (UPS), a regulated supply or is independent of other power
supplies (such as lighting, etc.). This will help to prevent malfunctions and premature aging of the
drivers and other components.

3.5.2 Connecting

• Make sure that the router's power supply switch is in the OFF position (0).
• Ensure the power supply is NOT connected to either the electricity supply or the router.
• Connect all data cables.
• Connect the power supply cable to the device.
• Connect the power supply cable to the electricity supply.
• Turn the router's power supply switch to the ON position (1).

3.5.3 Disconnecting

• Make sure that the router's power supply switch is in the OFF position (0).
• Disconnect the power supply from the electricity supply.
• Disconnect the power supply from the router.
• Disconnect the data cables.

3.6 RST button

The RST button on the rear of the Teldat M1 router has various functions (described below).

3.6.1 Rebooting the device

Once the device is operating normally, pressing the RST button will make it restart.

3.6.2 Default configuration

The RST button allows you to restore your router to its factory default configuration through the following steps:
• With the device switched off, keep the RST button pressed and switch the router on using the ON/OFF switch (1).
• The PSU LED lights up in green and the LED slot starts to blink in amber. This blinking will continue for 10
seconds.
• For the device to boot with the default configuration, stop pressing the RST button while the LED slot is blinking
(i.e., before the 10-second period expires).
The router's default configuration sets up the router with the following IP address and mask:
• IP address: 192.168.1.1
• IP mask: 255.255.255.0
Note
Some devices come with customized settings. As a result, the default configuration may be different to
the one shown above.

3.7 Connecting the data

The Teldat M1 router has the following data connections.
