SC6000 Series Smart Camera Quick Start Guide
Chapter 4 Device Installation and Wiring
4.1 Installation Preparation
You need to prepare following accessories before installation.
No.
Name
1
Lens*
2
Lens Cap
3
Light Source
4
Power and I/O Cable
5
GigE Network Cable
6
USB/VGA Cable
DC Switch Power
7
Supply*
8
Installation Bracket*
Note
Accessories with * mark mean that these items are not included in the device's package,
and you should purchase them separately in order to use the device normally.
4.2 Install Device
Before You Start
● Make sure the device in the package is in good condition and all the assembly parts are
included.
● Make sure that all the related devices are powered off during the installation.
Table 4-1 Accessories
Quantity
1
It refers to a C-mount lens.
1
It is included in the device and is removable.
It is used to provide the light and is optional.
Note
1
The light source should support SMR-03V-B
interface and it must be a constant voltage one.
It is a supplied 17-pin to open cable that is
1
included in the device's packaged.
It is a supplied aviation plug to RJ45 network
1
cable that is included in the device's packaged.
It is a supplied 17-pin cable that is included in the
1
device's packaged.
It should meet the device's power supply
1
requirements.
1
It is used to fix the device.
10
Description
