Module Identifiers - Ametek Solartron Analytical ModuLab XM ECS Installation Manual

Introducing ModuLab XM ECS
The external booster is used as an alternative to the internal booster, not an
addition. It is possible to have both of them installed in the same potentiostat
group, but they cannot both be used at the same time.

The modules are described in more detail in Section 1.6.
1.5.1

Module Identifiers

The modules are identified by their front panel labels, and by shortened versions
of the labels, limited to ten characters, which appear on the LCD display. The
labels identify the specific version of each module as shown in Table 1-1.
Software and Front
Panel Label
XM Pstat 1MS/s
XM FRA 1MHz
XM FRA 300kHz
XM Femto Ammeter
XM HV 100
XM HV 30
XM Booster 2A
Booster 12V/20A
Booster 24V/10A
Booster 50V/5A
Booster 50V/25A/125W
NOTE:
1-8
ModuLab XM ECS Electrochemical System: Installation Guide
Table 1-1 Module Identifiers
LCD
Label
Pstat 1MS
FRA 1MHz
FRA 300kHz
FA
HV 100
HV 30
Booster 2A
n/a
n/a
n/a
n/a
The external boosters have no LCD labels because they are not fitted
to the chassis.
Module Version
Potentiostat
Maximum data capture rate: 1M samples/second
Voltage span: ±8 V @ up to ±300 mA
Four auxiliary voltage channels are available as an
option.
FRA. Frequency range: 10
FRA. Frequency range: 10
Femto ammeter.
Current range (full scale): 3 pA to 300 mA
Capable of measuring currents < 1 fA.
High voltage module.
Output voltage span: ±100 V @ up to ±100 mA
High voltage module.
Output voltage span: ±30 V @ up to ±200 mA
Internal Power Booster.
Output: ±2 A @ voltage to match potentiostat or
HV module. (maximum voltage ±20 V)
External Power Booster.
Output: −3 V to +12 V @ ±20 A
External Power Booster.
Output: −3 V to +24 V @ ±10 A
External Power Booster.
Output: −3 V to +50 V @ ±5 A
External Power Booster.
Output: −3 V to +50 V @ –25 A to 0 A, (125 W
max)
Hz to 1 MHz
µ
Hz to 300 kHz
µ
21006002_AD 11/06/14
