DVNext Quick Start Guide
™
Instrument Setup
Assemble the Model G Laboratory Stand (refer to assembly instructions in Appendix K of the manual).
Put the rheometer on the stand.
Connect the RTD probe to the socket on the rear panel of the DVNext and connect the power cord.
Remove the shipping cap. For Cone/Plate Models, hold the Sample Cup and swing the tension bar away from the
bottom of the cup. Lower the cup and remove the foam insert. (Save for future shipments.)
Power Up
Turn on the DVNext. If the login screen appears, the password for the administrator login is admin.
Digital Leveling
After start-up, User will be prompted to level
the DVNext, follow the on-screen instructions.
Note: if the DVNext is level, there will be no
prompt for leveling.
AutoZero
Once leveling is complete, an AutoZero must
be performed before making a viscosity
measurement.
1.0
QS21-2101CP Rev.
(800) 528-7411 or (602) 470-1414
brookfieldengineering.com
brookfieldengineering.com
ZERO
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ametek BROOKFIELD DVNext
Summary of Contents for Ametek BROOKFIELD DVNext
- Page 1 (800) 528-7411 or (602) 470-1414 brookfieldengineering.com DVNext Quick Start Guide ™ Instrument Setup Assemble the Model G Laboratory Stand (refer to assembly instructions in Appendix K of the manual). Put the rheometer on the stand. Connect the RTD probe to the socket on the rear panel of the DVNext and connect the power cord. Remove the shipping cap.
- Page 2 Configure Viscosity Test If using the barcode scanner, ensure proper operation by scanning the barcode prior to initial use. In this screen, select spindle and speed. Confirm that Data Collection is set to Single Point and End Condition is set to Time 00:00:00. Note: DVNext Compliance has additional Accessory information.
