3.4.3 Monitor module (MM) functional description
The monitor module is situated at the right of the CCU. The following elements
are accessible from the front panel:
3.4.3.1. MM : Upper section
Groups all the elements over the speaker, dedicated to signals adjust,
number 6 must be in position 0. The leds Tx and Rx indicate that data is being
sent to, or received from, the control PC.
switch position
console nº 5 4
0 0 0
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 1
9 0 1
10 0 1
11 0 1
12 0 1
13 0 1
14 0 1
15 0 1
communications and monitoring.
• COMMON SIGNALS ADJUST: Five trimmers are found
at the top of the module, these allow the level adjustment
of the analog signal input common to all the modules:
International sound (IS) 1, : International sound (IS) 2,
CUE 1, CUE 2 and Public Address (PA).
3 2 1
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
Digital Commentary System
-62-
COMMUNICATIONS
• CCU ADDRESS:
This establishes
address, which is configured
between 0 and 31. The 6 dip-
switches numbered 1 to 6 are
used for this purpose. The
following table
switch settings for a determined
address which will be reflected
in the display. The dip-switch
switch position
console nº 5 4
16 1 0
17 1 0
18 1 0
19 1 0
20 1 0
21 1 0
22 1 0
23 1 0
24 1 1
25 1 1
26 1 1
27 1 1
28 1 1
29 1 1
30 1 1
31 1 1
the CCU
indicates the
3 2 1
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
