2.3.2.5 Dip switch configuration
The units feature four dip switches numbered from 1 to 4, which are accessible
on the rear panel, for access to cable equalization and the equipment software
configuration memories.
The ON position is down and the OFF position is up.
Cable equalization
Previous to connect the link cable from CU to CCU, dip switch number 2 must
be selected as shown below :
• If cable length is less than 150m., the dip switch number 2 must be set to ON
position (down).
• If cable length is greater than 150m., the dip switch number 2 must be set to
OFF position (up).
By this selection, the most proper equalization will be used to grant a low error
rate in the digital link circuits.
Functional configurations (There are several configurations programmed via
software to be selected before power on)
(1) Audio configuration 0
(1) Audio configuration 1
(2) Standard COM3 configuration
(3) BBC COM3 configuration
(4) INPUT TAPE standard configuration
(5) INPUT TAPE WITHOUT IS MIS config.
(1) There are 2 pre-programmed selectable configurations
(2) The commentator coordination circuit number 3 works in standard mode
(PTT) as required for most users
(3) The commentator coordination circuit number 3 works in commutation mode
as required by BBC
(4) The switch Channel ON of interview Mic channel or tape recorder just
opens the circuit.
(5) When the switch mic/line is in line position, the switch mentioned above
disables the mix of international sound with program If the circuit is opened,
avoiding the mix of IS with the signal introduced through line.
The application of each configuration is described with detail in the
corresponding section of chapter 4.
Digital Commentary System
-22-
SW 1 SW 2
SW 3
ON
-
-
OFF
-
-
-
-
-
-
-
-
-
-
ON
-
-
OFF
SW 4
-
-
ON
OFF
-
-
