The active version of the NIPC2 is connected to one of the room buses of the IP Room Controller. It has a
4-pin connector for the connection of the room bus, consisting of: 5.5Vdc, data, voice and ground (0V).
The room bus address is set by DIP switches.
The passive version must be connected to the passive bus of a door side module, a room display or a
toilet cancel module. It has a 4-pin connector for the connection of the passive bus, consisting of: 5.5Vdc,
Aux-In0, Aux-In1 and Aux-out.
Note: The 4-pole connector terminal required for the room bus is not supplied with the
switch module. It is available as an accessory and must be ordered separately.
The NIPC2 Pull Cord Module includes a special backplate with two urethane foam gaskets which makes
the NIPC2 splash water resistant to IP44 standard. The backplate must be mounted on a flat wall surface
using the four corner holes in the backplate.
The module is fixed on to the backplate by two latches and two screws through the cover plate. The
screws are supplied with the module.
WARNING:
17 July 2017 / Ver. PF3
The NIPC2 can only be mounted on the supplied IP44 backplate. It is not compatible
with the standard teleCARE switch module backplate and it is not compatible with the
teleCARE surface mounting spacer.
