Installation Guide
teleCARE IP
The multi color status LED on the NIRC3 will indicate the following:
NIRC3 - Status color
Steady blue
Steady orange
Fast blue flashing
Steady orange

System Faults

System faults like LAN failure, disconnected module will be visible through the yellow lamp on the NIRC3.
Fault - yellow LED
17 July 2017 / Ver. PF3
Status
Normal operation
Starting-up
Application start-up
Image installation mode
Figure 24. Fault indications on the NIRC3 yellow lamp
Status
LAN failure
Peripheral lost
Remarks
for about 22 seconds after
power on or reboot.
The NIRC3 will end up in image
installation mode after 4
unsuccessful boot attempts
Remarks
TD 93021US
28
