teleCARE IP
Connector for
the Speech
Module
Not supported
with UL 2560
systems
4-Pole Connector for the
Stereo Input from the
Figure 91. Bedside module NIMB2 electrical connections and address setting
The address is selected using the DIP switch on the switch module printed circuit board. For details of the
DIP switch settings see
For details of the 4-Pole connector see
For light switching relay details see
Diode on page
For details of connecting a speech module see
For details of connecting the external call see
71.
Note: The 4-pole connector terminals required for the room bus and other inputs and
outputs are not supplied with the switch module. They are available as accessories and
must be ordered separately.
17 July 2017 / Ver. PF3
4-Pole Connector
for the
Room Bus
Television Interface
6.4.10, Dip Switch Settings on page 67.
6.4.1, 4-Pole Connector Terminal on page
6.5.2, Light Switching Relay Maximum Load and Surge Damping
70.
4-Pole Connector
for an External Call Input
and Call LED Output
4-Pole Connector for
the Light Switching
6.15.1, Connecting the Speech Module on page
6.5.3, External Call Contact with Call Lamp Output on page
TD 93021US
Dip switch
for setting the
Room Bus
Address
0, 1, 2, or 3
Relays
60.
101.
69
