NUUTX Inputs

The NUUTX has two inputs that can be used to interface external alerts coming from a wide variety of
detectors. For example:
• Fire detectors
• Window/door open detector
• Low pressure switches to generate an alert from a resident
• Bed exit sensor
• Chair sensor
• Alerts from the building management system
The NUUTX features two independent inputs, supporting:
• Normally open (with line monitoring) and normally closed contacts
• Flashing contacts from 1 Hz
• A DC voltage from 10VDC to 30VDC
17 July 2017 / Ver. PF3
DRAFT
Figure 216. NUUTX inputs
