A18 Slab props

PEP Ergo B

Permissible prop load [kN] according to type test
PEP Ergo B-300
L = 1.97 – 3.00 m
Outer tube Inner tube
bottom bottom
2.00 30.0 30.0
2.10 29.8 30.0
2.20 27.0 30.0
2.30 24.6 30.0
2.40 23.0 30.0
2.50 21.4 30.0
2.60 20.3 29.5
2.70 19.3 27.4
2.80 18.2 24.8
2.90 16.9 22.2
3.00 15.6 20.2
3.10
3.20
3.30
3.40
3.50
Note:
PERI PEP Ergo B-300 and PEP Ergo B-350 Props meet
■
the load-bearing capacity requirements of Prop Class B
as stipulated in DIN EN 1065.
General Building Inspectorate Approval Z-8.311-934
■
issued by the German Institute for Building Technology
(DIBt).
SKYDECK Panel Slab Formwork
Instructions for Assembly and Use – Standard Configuration
PEP Ergo B-350
L = 2.25 – 3.50 m
Outer tube Inner tube
bottom bottom
30.0 28.6
28.6 28.6
25.5 28.6
23.1 28.3
21.2 28.0
19.8 27.4
18.6 26.0
17.5 24.4
16.3 22.7
15.2 20.8
14.2 19.0
13.2 17.4
12.4 15.7
