A15 Inclined slabs

Maximum permissible slab inclination with Tension Sleeve SAO and Chain 3.0 kN

Considered horizontal loads
Horizontal load from working operations
Horizontal load from the tilting position
Angle α between Chain and SLT 225
Max. tension force of Tension Sleeve SAO and Anchor Chain = 3.0 kN
Load
Slab thickness DIN EN 12812
[cm] [kN/m 2
14 5.13
16 5.62
18 6.11
20 6.60
22 7.09
24 7.58
25 7.83
26 8.07
28 8.56
30 9.05
35 10.38
40 11.73
43 12.54
45 13.08
50 14.43
55 15.77
60 17.12
65 18.47
70 19.82
75 21.08
80 22.30
85 23.53
90 24.75
Table A15.01
SKYDECK Tension Unit SD – bracing angle α selection
Angle α possible clear room height
Tension Unit with SSK and SLT 225
SD
min h
minimum clearance
30 ° 1.72 m
35 ° 2.02 m
40 ° 2.37 m
45 ° 2.77 m
50 ° 3.25 m
55 ° 3.84 m
60 ° 4.60 m
Table A15.02
66
= 1% of the vertical load (DIN EN 12812; 8.2.2.2)
= 1% of the vertical load (DIN EN 12812; 9.3.4.2)
= 60°
Panel span c = 1.50 m [cm]
increased prop
load Incline
] [kN]
20.3
22.0
23.7
25.4
27.1
28.7
29.6
30.4
32.1
33.8
38.4
43.1
45.9
possible clear room height
with SFK and SLT 225
max h min h
minimum clearance minimum clearance
2.01 m 1.73 m
2.34 m 2.04 m
2.71 m 2.39 m
3.12 m 2.80 m
3.60 m 3.28 m
4.16 m 3.88 m
4.87 m 4.65 m
max. slab inclination
Angle
[%] [°]
5.4 3.1
4.8 2.8
4.3 2.5
3.9 2.2
3.5 2.0
3.2 1.8
3.1 1.8
2.9 1.7
2.7 1.5
2.4 1.4
1.9 1.1
1.5 0.8
1.3 0.7
max h
minimum clearance
2.02 m
2.36 m
2.73 m
3.15 m
3.63 m
4.20 m
4.91 m
Instructions for Assembly and Use – Standard Configuration
Panel span c = 0.75 m [cm]
max. slab inclination
increased prop
load Incline
[kN] [%]
11.4 11.1
12.3 10.2
13.1 9.4
14.0 8.7
14.8 8.1
15.7 7.6
16.1 7.3
16.5 7.1
17.4 6.6
18.2 6.2
20.5 5.3
22.8 4.6
24.2 4.2
25.2 4.0
27.5 3.5
29.8 3.0
32.1 2.7
34.5 2.4
36.8 2.1
39.0 1.8
41.1 1.7
43.2 1.5
45.3 1.3
SKYDECK Panel Slab Formwork
Angle
[°]
6.3
5.8
5.4
5.0
4.6
4.3
4.2
4.1
3.8
3.6
3.0
2.6
2.4
2.3
2.0
1.7
1.5
1.3
1.2
1.1
0.9
0.8
0.8
