A18 Slab props

PEP 30

Permissible prop load [kN] according to the type test
PEP 30-150
L = 0.96 – 1.50 m
Outer tube Inner tube
bottom bottom
1.00 36.4 36.4
1.10 36.4 36.4
1.20 36.4 36.4
1.30 35.9 36.4
1.40 35.3 36.4
1.50 34.5 36.4
1.60
1.70
1.80
1.90
2.00
2.10
2.20
2.30
2.40
2.50
2.60
2.70
2.80
2.90
3.00
3.10
3.20
3.30
3.40
3.50
3.60
3.70
3.80
3.90
4.00
All PEP 30 Props correspond to Class E
of DIN EN 1065, i. e. the permissible
load for all extension lengths is a mini-
mum of 30 kN.
SKYDECK Panel Slab Formwork
Instructions for Assembly and Use – Standard Configuration
PEP 30-250
L = 1.46 – 2.50 m L = 1.71 – 3.00 m
Outer tube Inner tube Outer tube
bottom bottom bottom
42.9 42.9
42.9 42.9
42.9 42.9
42.1 42.9 42.9
39.7 42.9 42.9
37.9 42.9 42.9
36.4 42.9 42.9
35.5 42.9 42.9
34.3 41.5 42.9
33.1 38.7 42.7
31.0 35.9 41.1
40.0
38.5
36.9
34.2
31.3
When using PERI Slab Tables, the per-
missible load for all PEP 30 Props is a
minimum of 40 kN (PEP 30-150 = 35 kN)
over the entire extension lengths due to
the clamping in the Table Swivel Head
or UNIPORTAL Head.
PEP 30-300 PEP 30-350
L = 1.96 – 3.50 m
Inner tube Outer tube
bottom bottom
42.9
42.9
42.9 45.5
42.9 45.5
42.9 45.5
42.9 45.5
42.9 45.5
42.9 45.5
42.9 45.5
42.9 45.5
41.6 45.5
38.3 45.0
34.8 43.6
41.4
38.7
36.1
33.3
30.7
PEP 30-400
L = 2.21 – 4.00 m
Inner tube Outer tube Inner tube
bottom bottom bottom
45.5
45.5
45.5
45.5 41.5 41.5
45.5 41.5 41.5
45.5 41.5 41.5
45.5 41.5 41.5
45.5 41.5 41.5
45.5 41.5 41.5
45.5 41.5 41.5
45.5 41.5 41.5
44.2 41.5 41.5
42.1 41.5 41.5
38.7 41.5 41.5
35.7 41.5 41.5
32.5 41.5 41.5
41.5 41.5
41.3 41.5
38.5 41.3
35.9 38.1
33.2 34.9
79
