A9 SKYDECK platforms
Overview
The SKYDCK Platform SDB is a prefab-
ricated, foldable scaffold platform for
use as working scaffold following DIN
EN 12811, Load Class 2, with a permis-
sible load of 1.5 kN/m² (150 kg/m²). It
secures the open buiding edges of the
SKYDECK slab formwork.
Assembly of the slab formwork in con-
nection with SKYDECK Platform SDB is
carried out in four areas. ( I – IV)
The sequence must be maintained.
(Fig. A9.01)
SLT 375
II
Inner
platform
I
Outer
platform
SLT 375 Corner table
Fig. A9.01
46
Risk of falling!
– Ensure that end-to-end side pro-
tection is installed on slabs that
have been completed!
– Cantilevers should not have form-
work erected or be stepped on be-
fore being firmly secured with ten-
sion chains.
– Work to be carried out by qualified
personnel only!
When using SKYDECK platforms, no
safety scaffold is required for the levels
below.
SLT 225
IV
SDB 300
III
SDB 300 SDB 150
Instructions for Assembly and Use – Standard Configuration
SDB 225
SLT 375
SKYDECK Panel Slab Formwork
