Recessed Panels - Peri SKYDECK Instructions For Assembly And Use

A6 Shuttering around columns

3 recessed panels

Maximum column dimensions
x = 138 cm, y = 142 cm.
Secure filler plates with nails!
Install Edge Beam SRT-2 150 (9) vertically,
Edge Beam SRT-2 150 (9*) suspended,
Filler Timber SPH 150 (12) horizontally.
(Fig. A6.09, Fig. A6.10)
Additional Edge Beam SRT-2 150 (9)
required with:
Slab thickness Column side
d [m]
≤ 0.20 no additional SRT
0.25
0.30
0.40
Table A6.01
For other slab thicknesses, the values
are interpolated linearly.
Take into account the supporting
direction of the formlining.
36
Fig. A6.09
Fig. A6.10
Permissible width of influence of flat Filler Timber SPH,
maximum deformation l/500
y [m]
Slab thickness
≤ 0.40
14
≤ 0.70
16
≤ 1.15
18
20
22
24
25
26
28
30
35
40
43
Table A6.02
L L
SPH SPH
x
9* 12
permissible width of influence Filler Timber SPH flat e
with span L
100
30
26
23
21
19
18
17
16
15
14
12
11
10
Instructions for Assembly and Use – Standard Configuration
12
9
9
SPH,flat
[cm]
SPH
80 60
58 137
51 121
46 108
41 98
38 89
35 82
33 79
32 76
30 71
28 66
24 57
21 50
20 46
SKYDECK Panel Slab Formwork
[cm]
