Outline of the Programming Operation

Figure 3-1
Programming Operation
UniSite-xpi User Manual
Figure 3-1 shows an outline of the programming operation. The
programming operation is basically the same whether you use TaskLink
for Windows, TaskLink for DOS, or HiTerm as your user interface.
1. Select Device
Device Manufacturer &
Device Part Number
2. Load Device Data
Device Data
Programmer RAM
3. Program Device
Programmer RAM
Device in Socket
4. Verify Device
=
Data in Data in
Device RAM
1. The Select Device operation selects the manufacturer and part
number of the device you will be using so the programmer can
perform device operations with the appropriate programming
algorithm.
2. The Load Device Data operation moves device data from a master
device, hard drive, floppy disk drive, or network into programmer
RAM.
3. The Program Device operation transfers the device data in
programmer RAM into the device in the socket using the device's
programming algorithm.
4. The Verify Device operation (included with programming)
compares the data in a programmed device to the data in
programmer RAM. Additional verify operations provide information
about programming errors. Logic device verification can include
functional testing.
2869-1
