Texas Instruments SDSMAC Format, Code 90

Figure 6-17
An Example of TI SDSMAC Format
Byte Count
Tag Character
00050
90000BFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFF7F400F
90010BFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFF7F3FFF
90020BFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFF7F3FEF
90030BFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFF7F3FDF
90040BFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFFBFFFF7F3FCF
:
End-of-File Record
UniSite-xpi User Manual
Data files in the SDSMAC format consist of a start-of-file record, data
records, and an end-of-file record. See Figure 6-17.
Filename
Tag Character
Checksum
Tag Character
7FDD4F
Load Address
LEGEND
Nonprinting Carriage Return, with optional
line feed and nulls determined by null count.
Each record is composed of a series of small fields, each initiated by a tag
character. The programmer recognizes and acknowledges the following
tag characters:
0 or K—followed by a file header.
7—followed by a checksum which the programmer acknowledges.
8—followed by a checksum which the programmer ignores.
9—followed by a load address.
B—followed by 4 data characters.
F—denotes the end of a data record.
*—followed by 2 data characters.
The start-of-file record begins with a tag character and a 12-character file
header. The first four characters are the byte count of the data bytes; the
remaining file header characters are the name of the file and may be any
ASCII characters (in hex notation). Next come interspersed address fields
and data fields (each with tag characters). If any data fields appear before
the first address field in the file, the first of those data fields is assigned to
address 0000. Address fields may be expressed for any data byte, but
none are required.
The record ends with a checksum field initiated by the tag character 7 or
8, a 4-character checksum, and the tag character F. The checksum is the
two's complement of the sum of the 8-bit ASCII values of the characters,
beginning with the first tag character and ending with the checksum tag
character (7 or 8).
6. Translation Formats
Tag Characters
Data
Records
Checksum
