Program Device

Program Logic
Device
UniSite-xpi User Manual
* Compare Electronic ID (Y,N)—Compares the electronic ID of the
socketed device against the electronic ID of the selected algorithm.
* Odd/Even Byte Swap (Y,N)—When enabled, allows the Most
Significant Bytes (MSB) and the least significant bytes (LSB) of 16-bit
words to be swapped when data is loaded from a 16-bit device. When
disabled, the data from a 16-bit device is loaded into User RAM with
the MSB stored at an odd memory address. When enabled, the MSB
is stored at an even memory address.
The Program Device command allows you to copy data from RAM.
Depending on whether you select a logic or memory device, either the
Program Logic Device screen or the Program Memory Device screen
appears when you select this command. The Program Logic Device
command is explained first, and the Program Memory Device command
is explained next.
Before you can program a device, you need to load the programming
data into RAM.
If you select a logic device and then select the Program command, the
Program Logic Device menu appears.
Main
Menu
To program a logic device, follow these steps:
1. Select and socket a logic device.
2. Select Program Device from the Main Menu. The Program Logic
Device screen appears.
3. Specify the parameters you want, then press E
programming.
4. When the programming is complete, UniSite-xpi displays the
following message in the message bar:
OPERATION COMPLETE. Sumcheck = xxxx (8-bit)
The following parameters can be specified on the Program Logic Device
screen:
• Security Fuse Data (0,1)—To program the security fuse, set this
parameter to 1 and set the Program Security Fuse parameter to Y.
This parameter defaults to 0, which disables programming of the
security fuse.
Program
Device
NTER
4. Commands
Program
Logic
Param.
to begin the
4-13
