Preventive Maintenance for Modules (Legacy)

Error Conditions

SPA Block

Figure A-26. SPA Block and Base
BASE
UniSite-xpi User Manual
The following messages during device operations could result from dirt
in the SPA block or base adapter.
ID Error
Continuity Error
Base Adapter not Installed
Device Insertion Error
Overcurrent Error
Base / Adapter Relay Failure
To avoid error conditions caused by dirty or worn SPA blocks, we
recommend that you perform the following preventive maintenance
procedures.
• Keep the SPA block covered when it is not in use.
• To prevent base adapters from contaminating the SPA block, store
them in an uncontaminated area.
• Each time you remove or replace a programming module, clean the
SPA block with a brush.
• Inspect the SPA block for dirt weekly. Perform the following steps to
clean the SPA block:
1. Blow filtered compressed air across the SPA block.
2. Mildly dampen a small section of a lint-free cloth with a DeoxIT
pen (Data I/O P/N 570-5500-901) and gently rub the dampened
cloth across all the pins on the SPA block.
3. Using a clean section of the lint-free cloth, gently wipe the surface
again.
SPA BLOCK
A. Using Modules
2799-1
A-31
