Maintain the Previous
Configuration?
3. Press E to start the installation.
NTER
4. Follow any instructions displayed on the screen. For instance, if the
message
Insert Algorithm Set 3 Disk
Algorithm disk containing Algorithm Set 3.
CAUTION: Do not remove disks from UniSite-xpi during this operation
unless UniSite-xpi prompts you to do so.
When the Mass Storage software installation is done,
is displayed in the message bar.
COMPLETE
The commands on the Device Checks menu allow you to check devices
you want to program and to check data in user memory. Commands
available on this menu include the following:
• Sumcheck Display
• Compare Electronic ID
• Illegal Bit Check
• Blank Check
• Electronic Erase
• Underblow/Overblow (Logic Devices Only)
• Device Configure
Before you can execute a command described in this subsection, you
must do the following:
1. Select a device. For more information, see the section titled "Select a
Device" earlier in this chapter.
2. Insert and lock a device into the socket. (This applies only if you are
checking a device, not if you are checking User RAM.)
Type Y if you want the previous
configuration parameters to be
maintained after you install the new
version of software. If Y is selected, the
programmer will automatically update
the boot disk floppy with the
configuration parameters, then load
them onto the MSM. The factory
default settings are always accessible
through the Menu/Configure/Restore
screen.
If this option is disabled, then the
factory default configuration will be
installed.
appears, insert the
OPERATION
