Figure 6-22 Hewlett-Packard 64000 Unix Format - Data I/O UniSite-xpi User Manual

Figure 6-22
Hewlett-Packard 64000 Unix Format
8 words for
file name
Load Address
LS Word
Load Address
MS Word
Data Record
Number of bytes in
the following record
not including header
(or extra byte if present)
Load Address
LS Word
This data translation format was generated by a "dump utility" for illustrative purposes. Actual data
files are in binary code and are typically generated by the appropriate development software.
UniSite-xpi User Manual
The record length during upload is not affected by the upload record size
parameter in the Configure/Edit/Communication screen. It is
automatically set to transfer records using the maximum size (250 bytes)
except for the last record. The size of the last record will be set according
to the remaining number of data bytes.
Processor Information Record
Byte Count = 7
Data Bus
Header
Width
80 04 20 20 20 20 20 20-20 20 20 20 20 20 20 20
20 20 00 07 00 08 00 08-00 00 00 00 00 FF 00 FA
00 00 00 00 02 00 26 02-03 38 FF FF FF FF FF 02
30 38 FF FF FF FF FF 02-03 38 FF FF FF FF FF 02
03 38 FF FF FF FF FF 02-03 16 75 A8 00 75 82 10
75 D0 00 75 B8 10 75 89-20 75 88 40 75 98 50 75
97 00 E5 99 75 80 00 75-90 E0 75 A0 40 75 B0 FF
74 58 F5 70 F5 71 75 75-00 75 76 FF 51 FD E5 90
54 60 B4 00 05 75 8D A0-80 13 B4 20 05 75 BD F4
80 0B B4 40 05 75 8D E8-80 03 75 8D FD 75 A8 90
75 99 52 90 00 AD 7A 00-11 D5 31 02 51 79 90 00
B7 7A 10 11 D5 31 02 51-79 90 00 C1 7A 20 11 D5
31 02 51 79 90 00 CB 7A-30 11 D5 31 02 51 79 80
D2 03 07 0B 13 11 17 1F-1D 23 00 02 06 0A 12 10
16 1E 1C 22 00 01 05 09-0D 0F 15 19 1B 21 25 00
04 08 0C 0E 14 18 1A 20-14 78 00 EA 44 40 FA 75
A0 4F E8 93 24 30 F9 87-80 EA 54 4F F5 A0 0A 08
75 A0 4F B8 0A EC EA 54-3F F5 A0 78 28 00 00 FF
00 FA 00 FA 00 00 00 00-00 D8 FA 8A A0 22 A8 71
F8 B5 70 01 22 E6 08 B8-70 02 78 58 88 71 F9 B4
E7 08 B8-72 90 01 22 93 73 06 30
Load Address
MS Word
Data Width Transfer
Base Address MS
Transfer
Address LS
00 26 B4 5A 07 51 FD
B4 00 80 BF B4
Data Record
6. Translation Formats
Number of bytes in
the following record
including header
Number of bytes in
the following record
not including header
End of first 124
record words
Number of bytes in
the following record
