Complement Data
Data Copy
UniSite-xpi User Manual
Command Keystrokes Description
Toggle T
AB
Hex/ASCII
Modes
The Complement command converts each bit of data within the specified
data block to its opposite value (one's complement).
More Edit Data
Com-
mands
To complement data stored in memory, follow these steps:
1. Specify the parameters described below.
2. Press E to begin the complement function. UniSite-xpi displays
NTER
the following message when the operation is completed.
Done
The available parameters are described below.
• Memory Address—The memory address at which the complement
operation begins. The value entered may be any 1- to 6-digit hex
address. The address cannot be greater than the User RAM size.
• Block Size—The number of bytes (in hex) that is complemented.
Move the cursor to the block size window and enter the block size
(from 1 to 6 hex digits). The block size, added to the memory address,
cannot exceed the user memory size.
The Data Copy command copies a block of data from one location to
another.
More Edit Data
Com-
mands
To copy data stored in memory, follow these steps:
1. Specify the parameters described below.
2. Press E to begin the Data Copy operation. UniSite-xpi displays
NTER
when the process is complete.
Done
Toggles the mode for data entry. When
in hex mode, data is entered on the left
side of the screen and the only valid
entries are hex characters. When in
ASCII mode, data is entered on the right
side of the screen and any printable
ASCII character can be entered. ASCII
mode is not allowed when in 4-bit mode.
Comp.
Data Copy
4. Commands
Comp. Pro-
grammer
Memory
Move Pro-
grammer
Memory
