Data I/O UniSite-xpi User Manual page 210

4. Commands
Purge File
Rename File
4-76
This command deletes a file, or group of files, from a disk.
Main More
Menu Com-
mands
To purge a file from a disk, follow these steps:
1. Insert the disk with the file you want to delete into one of the disk
drives.
2. When you select the Purge File command, the dialog window fills
with a directory listing. UniSite-xpi displays up to 28 files at one time.
If there are more than 28 files, press C
page of files. Press C
If you do not see the file you want to delete, press F2, insert another
disk, and return to the beginning of this step.
3. Move the cursor to the Filename field and enter the name of the file
you want to delete. Remember to specify which drive holds the file
you want to delete.
Note: You can use an asterisk (*) as a wildcard. For example, to purge both
27512.dat and 27128.dat, you could type 27*.dat.
4. Move the cursor to the Are you sure? field and press Y.
CAUTION: If you do not want to delete the file, do not press Enter.
5. To delete the file, press E
press F2 to return to the File Operations menu.
This command changes the name of a file.
Main More
Menu Com-
mands
To rename a file, follow these steps:
1. Insert the disk with the file you want to rename into one of the disk
drives.
Note: You cannot rename a file to a different disk drive than the current one
displayed on the screen.
2. When you select the Rename File command, the dialog window fills
with the directory listing. UniSite-xpi displays up to 28 files at one
time. If there are more than 28 files, press C
next page of files. Press C
If you do not see the file you want to rename, press F2, insert another
disk, and return to the beginning of this step.
File Oper-
ations
+ N to display the next
TRL
+ P to display the previous page of files.
TRL
. If you do not want to delete the file,
NTER
File Oper-
ations
TRL
+ P to display the previous page of files.
TRL
Purge
Data File
Rename
Data File
+ N to display the
