Quad Flat Pack Device
Orientation
Figure A-19
QFP Device Orientation
Shrink Dip Device
Figure A-20
Shrink Dip Device Orientation
UniSite-xpi User Manual
Pin 1 on the QFP device is usually at the front left of the device. Orient the
QFP device according to the icon or indicator on the adapter.
DEVICE
PIN 1
QFP SOCKET
Orient the SDIP device in the socket with pin 1 at the top left and bottom
justified as shown in Figure A-20.
SDIP SOCKET
PIN 1
SDIP ORIENTATION
ICON
PIN 1
A. Using Modules
