Elevation / Azimuth:
The function "Elevation / Azimuth" (1) displays the current position of the sun (horizontal
and vertical) starting from the observation location.
2
1
Figure 59: Parameter of the „Elevation / Azimuth" function
The function has favorites within the symbol library (2). Additional icons are available via the
" " button.
Function Selection of the icon library in SV-Control Operating and display element in SV-Home
Elevation /
Azimuth
Table 41: Display of the „Elevation / Azimuth" function
