Value transmitter
The function type "value transmitter" can optionally be represented by three differentiated
KNX functions.
Send 1 Byte (0...255%):
The function "Send 1 byte" (1) is the KNX function with which 1-byte percentage values can
be set. This is passed on via the group address "Value" (2).
In addition, a predefined value can be set via "Send value" and the range can be defined via
"Value range" (3).
Figure 54: Parameter of the "Send 1 byte (0...255%)" function
The function has favorites within the symbol library (4). Additional icons are available via the
" " button.
KNX-funktion Selection of the icon library in SV-Control
Send
1 byte
(0...255%)
Table 36: Display of the "Send 1 byte (0...255%)" function
SV-SERVER-01 / SV-SERVER-INT
4
1
2
3
Operating and display element in SV-Home
