Value / State
The function type "Value / Status" can optionally be mapped by 12 differentiated KNX
functions.
Display 1-Bit (boolean):
The function "Display 1-bit" (1) is the KNX function for displaying one-bit status values of the
KNX system.
The function reads the KNX group address entered in the input field "Status (1 Bit)" (2). In
addition, the current status of the function can be polled by defining two initialisation
addresses (3) on starting the system.
The value conversion (4) can be used to invert the result by pressing the check mark.
5
1
2
3
4
Figure 42: Parameters of the "Display 1-bit values" function
SV-SERVER-01 / SV-SERVER-INT
69 / 157
