2.4.9 Editing or deleting a function

Access as Administrator or User
The "User" and the "Administrator" have different access rights to KNX functions within the
"Functions" column.
Access as Administrator
Select an existing function (1) to edit or delete it. The "Functions" column lists all the
existing functions.
The arrow buttons "
" (2) you to change the order of an area, after selecting it, and thus
to move the position in SV-Home. The top most function in SV-Control (from top to bottom)
is also displayed as the first function in SV-Home (from top to bottom).
It is possible to change the effect of the selected function (3), assign an alternative icon by
pressing the currently selected icon " " (4), edit the name of the function (5) and, beneath
that, add a description (6).
The changes are automatically saved and briefly displayed by a green "Save successful"
screen.
In addition, the button "
/
" (8) indicates whether the entries of the group addresses
are complete.To fully delete the selected area (assuming Administrator rights), press the "
" button (8).
Deletion of an area does not delete the functions assigned to it.
7
8
2
4
5
1
6
3
Figure 64: Organisation of the "Areas & Functions" tab
SV-SERVER-01 / SV-SERVER-INT
103 / 157
