1.7.1 SV-Home – User interface
The SV-Home is the integrated web interface of the Smart Visu Server for the visualisation,
status display and operation of the KNX system and the Philips Hue system. The SV-Home
is generated automatically from the configuration set up in SV-Control.
A current HTML5-compatible browser (input device) is required for access to SV-Home.
Recommended is the access of max. 10 different clients on the SV-Home web interface.
When the server is opened, the SV-Home visualisation can be started by selecting the left
button or http://IP-address/SV-Home/ (1).
The top pane (1) displays the areas created in SV-Control with the selected icon and name.
It is also possible to display the defined area of the actions. Selecting an area displays the
assigned functions and actions (2) beneath.
Depending on the created function type, these functions visualise their status (e.g. the
current room temperature) or offer a chance to influence it (e.g. move a Venetian blind or
dim a Philips Hue lamp).
SV-SERVER-01 / SV-SERVER-INT
1
Figure 3: Opening SV-Home
Figure 4: Structure of the SV-Home visualisation
Areas (1)
Functions / actions (2)
