Ventilate:
The "Ventilate" function (1) allows the display and control of the status of a KNX ventilation
controller.
In the input field (2), it is possible to specify the group address for controlling the fan and, in
the input field (3), it is possible to enter the group address for the feedback of the currently
set fan step.
One of the two group addresses can be selected for the initialisation (4) of the Smart Visu
Server on its system start.
5
1
2
3
4
Figure 31: Parameters of the "Ventilate" function
The function has favorites within the symbol library (5). Additional icons are available via the
"
" button.
Selection of the icon library
Operating and display element
KNX function
in SV-Control
in SV-Home
Ventilate
Table 13: Display of the "Ventilate" function
SV-SERVER-01 / SV-SERVER-INT
52 / 157
