Venetian Blinds (Button):
The "Venetian Blinds (Button)" function (1) is the KNX function for controlling motorised
Venetian blinds with position and slat specification. The motorised drive can be activated by
the group addresses "Long time" (2), "Short time" (3), "Position specification" (4) and "Slat
specification" (5).
To read the positions, it is possible to configured the group addresses "Feedback position"
(6) and "Slat feedback" (7).
In addition, the current status of the function can be polled by defining two initialisation
addresses (8 - 9) on starting the system.
Figure 29: Parameters of the "Venetian Blinds (Button)" function
SV-SERVER-01 / SV-SERVER-INT
10
1
2
3
4
6
8
5
7
9
49 / 157
