Send 2 Byte (lux):
The function "Send 2 byte" (1) is the KNX function with which 2 byte lux values can be set.
This is passed on via the group address "Value" (2).
In addition, a predefined value can be set via "Send value" and the range can be defined via
"Value range" (3).
Figure 55: Parameter of the "Send 2 byte (lux)" function
The function has favorites within the symbol library (4). Additional icons are available via the
"
" button.
KNX-funktion
Selection of the icon library in SV-Control
Send
2 byte
(0...99999)
Table 37: Display of the "Send 2 byte (lux)" function
SV-SERVER-01 / SV-SERVER-INT
4
1
2
3
Operating and display element in SV-Home
84 / 157
