Switch / Dimmer
If required, the function type "Switch / Dimmer" can be depicted by four KNX functions.
Switch:
The "Switch" function (1) is the standard KNX function for simply switching on and off of
switching actuators. In the "Switch" function, a group address can be defined for writing
"Switch" status changes (2) as can a group address for reading "Switch feedback" feedback
(3).
In addition, the current status of a group address can be polled by defining an initialisation
address (4) on starting the system.
The function has favorites within the symbol library (5). Additional icons are available via the
"
" button.
KNX function
Selection of the icon library in SV-Control
Switch
SV-SERVER-01 / SV-SERVER-INT
5
Figure 20: Parameters of the "Switch" function
Table 2: Display of the "Switch" function
1
2
3
4
Operating and display element in SV-Home
37 / 157
