Smart Visu Server
Smart Visu Server
Ref.-no.: SV-SERVER,
SV-SERVER-INT
Operating instructions

1 Safety instructions

Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
These instructions are an integral part of the product and must remain with the end customer.
This product is only intended for use in dry rooms.

2 Device components

(1) Power supply
(2) Ethernet interface
(3) USB interface
(4) Discharge protection
(5) Status LED
(6) Reset button
0024074401
4
5
6
3
2
1
Fig. 1: Device components
Only use the power supply unit from the scope of delivery.
For connection to the local IP network
For software updates
Remove for operation
Displays the current status of the server
Reset and update
1 / 4
GB
11.08.2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV-SERVER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jung SV-SERVER

Summary of Contents for Jung SV-SERVER

  • Page 1 Smart Visu Server Smart Visu Server Ref.-no.: SV-SERVER, SV-SERVER-INT Operating instructions 1 Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. Serious injuries, fire or property damage possible. Please read and follow manual fully. These instructions are an integral part of the product and must remain with the end customer.
  • Page 2 - Power supply unit with plug - SV-SERVER: EU power supply unit (Euro plug) - SV-SERVER-INT: Power supply unit, including adapter for BS (United Kingdom), EU (Euro plug) and CN (China) 4 Information for electrically skilled persons Installation and electrical connection DANGER Electrical shock on contact with live parts in the installation environment.
  • Page 3 As soon as the Status LED (5) turns blue, the server is ready for operation. • In the address line of the Internet browser, enter: http://sv-server.local Fig. 2: Address of the server This opens the homepage of the server. If the homepage is not opened, then determine the IP address of the server in the router manually.
  • Page 4 Fig. 4: SV-Control For more details about further start-up steps and data import, please refer to the technical documentation, which can be found on the server (SV-Control) or on the Internet at www.jung.de. 7 Disposal of batteries This device includes an integrated battery.At the end of its useful life, dispose of the device together with the battery in accordance with the environmental regulations.
