The "Activate and Learn Scene (KNX)" function (1) is a Smart Visu Server function for
executing KNX scenes. This is currently only with a terminal (PC or similar) including mouse
usable.
The function transmits a scene value (2) to the KNX group address entered in the input field
"Scene group address (1 Byte)" (3). With each KNX scene group address, up to 64 scene
values (or scene numbers) (2) can be recalled. The scene value (2) the Smart Visu Server
should transmit when a scene is triggered can be set in the input field (2).
Figure 41: Parameters of the "Activate and learn" function
The function has favorites within the symbol library (4). Additional icons are available via the
"
" button.
KNX
Selection of the icon library in SV-Control
function
Activate
& learn
scene
Table 23: Display of the "Activate & learn scene" function
SV-SERVER-01 / SV-SERVER-INT
4
2
1
2
Operating and display element in SV-Home
68 / 157
