Dimmer:
The "Dimmer" function (1) is used for simple dimming of dimmer actuators. A "Brightness
value" (2) group address can be configured for switching or writing a new brightness value.
In the same way, to read the feedback, it is possible to configured the group addresses
"Brightness value feedback" (3).
In addition, the current status of a selectable group address can be polled by defining an
initialisation address (5) on starting the system.
Figure 22: Parameters of the "Dimmer" function
The function has favorites within the symbol library (5). Additional icons are available via the
" " button.
Auswahl der Symbol-Bibliothek
KNX-Funktion
Dimmer
SV-SERVER-01 / SV-SERVER-INT
5
im SV-Control
Table 4: Darstellung der Funktion „Dimmer"
1
2
3
4
Bedien- und Anzeigeelement
in der SV-Home
