Base Setpoint:
The Smart Visu Server supports KNX climate control by specifying a base setpoint (1). The
temperature control can be influenced by the group address "basic setpoint" (2).
The reading of the current setpoint and the current actual value can be configured by the
group addresses "Display temperature" (3) and "Actual temperature" (4).
In addition, by defining three initialization addresses (5 - 7) at system startup, the current
status of the function can be queried.
Moreover, the "Range of values" (8) can be set individually.
Figure 34: Parameters of the "Base Setpoint" function
The function has favorites within the symbol library (9). Additional icons are available via the
" " button.
KNX function Selection of the icon library in SV-Control
Base Setpoint
SV-SERVER-01 / SV-SERVER-INT
9
Table 16: Display of the "Base Setpoint" function
1
2
5
3
6
4
7
8
Operating and display element in SV-Home
