2 SV-Control

This chapter describes the configuration and commissioning of the Smart Visu Server using
SV-Control in detail.

2.1 Project tab

The "Project" tab serves as the homepage of SV-Control. Here, it is possible to set the
required language (1), start project design (2), back up the overall project (3) or restore a
previously backed up project (4).
After project design has been completed, access to the project design functions can be
protected by assigning a password (5).
In addition, the product documentation (6) is stored in SV-Control in German and English.

2.1.1 Manage language

The desired project design language (1) can be specified in the "Project" tab. It is possible
to change over the language settings during commissioning or at a later time.
The following languages are available in the selection menu (1):
- German
- Italian
- Estonia
- Ukrainian

2.1.2 Start

Begin project design of the Smart Visu Server using the "

2.1.3 Backing up a project

The backup of the current project design can be triggered using the "
operation can take a moment to complete. Then, the project design can be downloaded
using the "
" button (3).
SV-SERVER-01 / SV-SERVER-INT
2
3
4
Figure 7: SV-Control, Project tab
- English
- Spainish
- Lithuanian
- Korean
- French
- Dutch
- Portuguese
- Russian
- Latvian
- Polnish
- chinese
" button (2).
5
6
1
" button (3). This
