4 Update of the Smart Visu Server

JUNG is always working to improve the support and functionality of the SV Server. In the
context of these efforts, we make updates for the system software available.

4.1 Reading out the software version

You can read out the software version currently installed on your Smart Visu Server via
SV-Control. This is shown at the bottom of all the tabs of SV-Control behind the text "SW
VERSION:" (1).

4.2 Performing a system update

To perform a system update, the Smart Visu Server requires access to the Internet.
Depending on the speed of the available Internet connection, this operation can take
several minutes.
We recommend not interrupting the power and network connection for the period of the
update. In addition, we do not recommend making any changes in SV-Control during
execution. The Status LED (5) of the device flashes periodically in magenta whilst the
update is being performed.
A system update can be triggered both via SV-Control (see Chapter 2.6.4 Server update)
and via the pushbutton (4) of the Smart Visu Server.
In addition, it is possible to import a server update via USB stick. Corresponding manuel
steps, please refer to the separate instructions on our website.
To perform the system update using the pushbutton (5) on the device, press the button 5
times quickly in succession. If an update is available, this is then downloaded automatically
and installed. When the update has been completed, the Smart Visu Server restarts
automatically. (https://www.jung.de/en/)
SV-SERVER-01 / SV-SERVER-INT
1
Figure 115: Homepage of SV-Control
T
h
is
is
a
d
d
e
d
t
o
t
h
e
a
r
e
a
li
s
t
w
it
h
it
s
n
a
m
e
a
n
d
is
Figure 116: Smart Visu Server
s
e
l
e
c
t
129 / 157
