Dimmer/Switch:
The "Dimmer + Switch" function (1) is used for simple dimming of dimmer actuators. A
"Switching" (2) and / or "Brightness value" (4) group address can be configured for switching
or writing a new brightness value. In the same way, to read the feedback, it is possible to
configured the group addresses "Switching feedback" (3) and "Brightness value feedback"
(5).
In addition, the current status of a selectable group address can be polled by defining an
initialisation address (6) on starting the system.
Figure 23: Parameters of the "Dimmer/Switch" function
The function has favorites within the symbol library (7). Additional icons are available via the
" " button.
KNX function Selection of the icon library in SV-Control
Dimmer +
Switch
SV-SERVER-01 / SV-SERVER-INT
7
Table 5: Display of the "Dimmer" function
1
2
3
6
4
5
Operating and display element in SV-Home
