Root NIBPT
Reference Example
1
2
Downloading Screen Captures
To download screen captures:
1. Remove any sensors connected to the patient to stop monitoring, and
acknowledge any alarms triggered on Root.
Note: Before connecting the USB drive in the next step, there must be a folder
titled "screen_shot" in the USB drive with a FAT or FAT32 system file to enable the
download of the screen captures.
2. Plug the USB drive into the USB port located on the rear panel of Root; the screen
captures will automatically download. A status message will display briefly at the
top of the Root screen to indicate the start of the download.
3. A confirmation status message will display briefly at the top of the Root screen
when the file transfer is complete.
4. Unplug the USB drive from Root.
To import the screen captures from the USB drive onto a computer, plug the USB drive into
the computers USB port, then open the folder titled "screen_shot" (from the USB drive) on
the computer to access the .png files.
www.masimo.com
Description
The screen capture status message
displays the following information:
•
Date: Date of screen capture
(YYYYMMDD)
•
Time: Time of screen capture
(HHMMSS)
•
Device Serial Number: 10 digit
Root serial number
•
Number of Screen Captures:
The number of screen captures
saved on Root of 20 screen
capture limit. When the limit of
20 screen captures is reached,
every new screen capture will
replace the oldest dated screen
capture.
The patient label is masked with
asterisks when capturing a screen.
85
Chapter 3: Operation
