Root NIBPT
Side Views
Left Side
Ref. Feature
1 System Status Lights
2
Power Button
3
MOC-9 Ports (3)
4 NIBP Nib
5
Temperature Probe Port*
Temperature Probe Well Holder* Provides dock for temperature probe when not
6
7 Probe Covers Holder
*This feature is optional on Root
www.masimo.com
Description
Provides an indication of system messages and
alarm priority. See System Status Lights on page
86.
Places Root in Power On, Sleep, and Power Off
modes.
Provide connectivity for MOC-9 modules.
Connection port for NIBP Hose.
Allows connection of temperature probe to Root.
measuring.
Holds extra probe covers for quick access.
24
Chapter 1: Description
Right Side
