Root NIBPT
Using Trend View
In Trend View, a parameter or measurement is displayed as a graph of its values over time.
The following diagram and table describe key features of a parameter's Trend Display in
Trend View.
Ref. Feature
1
Value Range
2 Trend Graph
3
Numeric Value
4
Alarm Limits
Parameter or
5
Measurement Label Indicates the name of the parameter or measurement.
www.masimo.com
Description
Indicates current viewing of the parameter or measurement.
Press to access the Trend menu where the minimum and
maximum of the range can be modified.
Displays parameter and measurement over a period of time.
Zoom in and out of a Trend Graph by pinching out and in.
Indicates current reading of the parameter or measurement.
Indicate high and low alarm limits for the parameter or
measurement, if supported.
